ResultsResults
To replace the component, reverse the removal procedure.
Drive replacementDrive replacement
SubtopicsSubtopics
Removing and replacing an LFF driveRemoving and replacing an LFF drive
Removing and replacing an SFF driveRemoving and replacing an SFF drive
Removing and replacing an LFF driveRemoving and replacing an LFF drive
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
About this taskAbout this task
CAUTION:CAUTION: A discharge of static electricity from a finger or other conductor might damage system boards or other static-
sensitive devices. To prevent damage, observe antistatic precautions.
ProcedureProcedure
1. Power down the server.
2. Disconnect the power cord from the AC source.
3. Remove the power adapter cord from the power cord clamp, and then disconnect the power adapter from the server.
4. Disconnect all peripheral cables from the server.
5. If installed, unlock and remove the security padlock and/or the Kensington security lock.
For more information, see the lock documentation.
6. If the server is in a vertical orientation, position the server in a horizontal orientation.
