Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd.
―8― HD3L Series Controller User Manual
Input / Output
Analogue power supply +10V, max. current 100mA
Digital power supply +24V, max. current 200mA
Analogue input
AI1 (control board): voltage 0 - 10V
AI2 (control board): -10 - +10V/0 - 20mA (selectable voltage / current)
AI3, AI4 (I/O board): -10 - +10V/0 - 20mA (selectable voltage / current; AI4 supports
differential input )
Analogue output AO1, AO2: 0 - 10V/0 - 20mA (selectable voltage / current)
Digital input DI1 - DI6 (control board); DI7 - DI9 (I/O board)
Digital output DO1, DO2
Relay output
R1A/R1B/R1C (control board)
R2A/R2B/R2C, R3A/R3B/R3C, R4A/R4B/R4C (I/O board)
Contact rating 250VAC/3A or 30VDC/1A
Communication
SCI communication RS-485 interface; Terminal
Keypad
LED display
Five LEDs display
Setting function parameter, checking status parameters, checking fault code, etc.
Indicators 5 unit indicators, 5 status indicators
Parameter copy Achieve quick parameter copy
Environment
Running temperature
-10 - +40
℃
, max. 50
℃
, air temperature fluctuation is less than 0.5
℃
/min
The derating value of output current of HD3L shall be 2% for each degree centigrade
above 40
℃
. Max. allowed temperature is 50
℃
Storage temperature -40 - +70
℃
Location for use
Indoor, preventing from direct sunlight, no dust, corrosive, flammable gases, oil mist,
water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Oscillation Less than 5.9m/s
2
(0.6g)
Protection class IP20
Pollution level Level 2 (Dry, non conducting dust pollution)
Accessories
About keypad
Mounting base to keypad [HD-KMB]
1m/2m/3m/6m extension cable to keypad [HD-CAB-1M/2M/3M/6M]
Power units Power regenerative unit [HDRU]
