Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
64 HD3L Series Controller User Manual
Ref. Code Function Description Setting Range [Default]
F15.11 Set parameter 4 of stop status 0 - 32 [26]
F15.12 Set parameter 5 of stop status 0 - 32 [27]
F15.13 Set parameter 6 of stop status 0 - 32 [0]
The keypad displays parameters which is the run status (F15.02 - F15.07) and stop status (F15.08 - F15.13).
It can be cycling displayed by key on the keypad.
Each content of display parameter can be set corresponding to 32 statuses.
For instance: when set F15.08 = 7, the stop parameter is setting RPM at initial power on.
0: Unused.
1: Rated current of HD3L.
2: Controller status. Refer to d00.06.
3: Operate channel.
4: Setting speed.
5: Setting speed (after Acc / Dec).
6: Output frequency.
7: Setting RPM.
8: Running RPM.
9: Unused.
10: Output voltage.
11: Output current.
12: Output torque.
13: Output power.
14: DC bus voltage.
15: AI1 voltage.
16: AI1 voltage (after calculating).
17: AI2 voltage.
18: AI2 voltage (after calculating).
19: AI3 voltage.
20: AI3 voltage (after calculating).
21: AI4 voltage.
22: AI4 voltage (after calculating).
23: AO1 output.
24: AO2 output.
25: Heatsink temperature.
26: Input terminal status.
Bit0 - Bit11 correspond to DI1 - DI12.
27: Output terminal status.
Bit0 - Bit5 correspond to DO1, DO2 and RLY1 -
RLY4.
28: MODBUS status.
29: Total time at power on (hour).
30: Total running time (hour).
31: Unused.
32: Unused.
6.2.14 F16: Function-boost Parameters
Ref. Code Function Description Setting Range [Default]
F16.00 Zero-speed running signal delay time 0.00 - 10.00 [0.30s]
Defines the delay time of HD3L from zero-speed run status to zero-speed run signal output.
F16.01 Zero-speed signal delay time 0.00 - 10.00 [0.30s]
Defines the delay time of HD3Lfrom zero-speed status to zero-speed signal output.
F16.02 Current keep time after stop 0 - 9999 [0ms]
To eliminate the current noise of motor at stop, when the brake finished, the cut-off run signal will reduce the
current to zero after the time of F16.02.
F16.03 Fan control 0 - 2 [0]
Defines the fan control mode. If there is overheat protection, the fan will run all the time.
0: Auto stop.
The fan runs all the time when HD3L is in run status. After HD3L stops for the time of F16.04, the fan
continues running if overheat protection is activated.
1: Immediately stop.
The fan runs all the time when HD3L is in running status, but stops when HD3L stops.
2: Run when power on.
The fan runs continuously after HD3L is switched on.
