Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3L Series Controller User Manual 43
6.1.2 d01: Drive Status Parameters
Ref. Code Function Description Setting Range [Default]
d01.00 Control mode [Actual value]
Display cotrol mode.
d01.01 Setting speed (m/s) [Actual value]
Display setting speed.
d01.02 Setting speed (after Acc / Dec) (m/s) [Actual value]
Display speed which is calculated by Acc / Dec S curve.
d01.03 Feedback speed (m/s) [Actual value]
Display actual speed of elevator.
d01.04 Setting frequency [Actual value]
Display setting frequency.
d01.05 Setting frequency (after Acc / Dec) [Actual value]
Display frequency (after Acc / Dec).
d01.06 Output frequency [Actual value]
Display output frequency.
d01.07 Setting RPM [Actual value]
Display setting RPM.
d01.08 Running RPM [Actual value]
Display running RPM.
d01.09 Unused
d01.10 Output voltage [Actual value]
Display output voltage.
d01.11 Output current [Actual value]
Display output current.
d01.12 Output torque [Actual value]
Display output torque which is the relative percentage of rated torque of motor.
d01.13 Output power [Actual value]
Display output power which is the relative percentage of rated power of motor.
d01.14 DC bus voltage [Actual value]
Display DC bus voltage.
d01.15 - d01.16 Unused
6
