Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Function Introduction
HD3L Series Controller User Manual ―59―
Ref. Code Function Description Setting Range [Default]
4 - 6: Multi-speed 1 - 3 (MS1 - MS3).
• Achieve 8-speed running curve via terminals logic combination, as follow table.
MS3 (No. 6) MS2 (No. 5) MS1 (No. 4) Multi-speed Setting
0 0 0 Multi-speed 0 (F05.00)
0 0 1 Multi-speed 1 (F05.01)
0 1 0 Multi-speed 2 (F05.02)
0 1 1 Multi-speed 3 (F05.03)
1 0 0 Multi-speed 4 (F05.04)
1 0 1 Multi-speed 5 (F05.05)
1 1 0 Multi-speed 6 (F05.06)
1 1 1 Multi-speed 7 (F05.07)
123
7: Inspection input (INS).
• If enabled, elevator will do inspection running.
• This signal, when used together with UP / DN (No. 2 or No. 3 function) command, can control the
elevator to go up or down during inspection.
8: Battery-driven input (BAT).
• If enabled, elevator will enter battery-driven running status.
9: Contactor feedback input (CSM).
10: Brake feedback input (BSM).
11 - 14: Weighing signal input 1 - 4 (WD1 - WD4).
• The switch weight signals can input through this terminal. Based on these signals, HD3L sets the torque
bias and starts the elevator stably.
• Select among WD1 - WD4 according to the actual number of weighing devices and set the load of
switches based on F06.08 – F06.11 (DI weighing signal 1 - 4).
• If many terminals are enabled, the max. No. terminal will be enabled.
For example: When WD1 and WD2 are enabled simultaneously, only WD2 is the valid one.
15: Motor overheat input (OH).
16: Fault reset input (RST).
• When HD3L alarms fault, reset it by this terminal.
• The function of RST terminal is the same as the key.
17: Up forced speed input (UPF).
18: Down forced speed input (DNF).
19: Governor feedback input (OSG).
20 - 33 : Unused.
34: External fault (EXT).
• The fault signal of external equipment can input through this terminal, so HD3L can monitor that
equipment and respond accordingly. HD3L alarms E0024 fault (external fault) when receives the EXT
signal.
F12.13 Filter time of multi-speed terminal 0.000 - 2.000s [0.010]
Defines the MS filter time to make up for the time error of MS input terminals.
• Change F12.13 according to the change asynchronous level of numbers of MS input terminals.
F12.14 Unused
F12.15 DO1 function 0 - 19 [2]
F12.16 DO2 function 0 - 19 [3]
F12.17 RLY1 function 0 - 19 [14]
