KP806
User Manual
Rev.1.0
19
4 INTERFACES
Printer KP806 supports cash drawer interface and many other various communicate interfaces:USB
interface, Ethernet interface
4.1 USB
PIN NO.
Signal Name
1
VBUS
2
D-
3
D+
4
GND
4.2 Ethernet Interface
PIN No.
Signal Name
1
TX+
2
TX-
3
RX+
4
-
5
-
6
RX+
7
-
8
-
