TP801/TP805/TP806 User Manual
www.hprt.com 10
2.2 Printing media specification
2.2.1 Continuous thermal paper specification
 Paper type: thermal continuous paper/thermal black mark paper/thermal label
paper.
 Paper width： 80±0.5 mm, 57.5±0.5 mm.
 Paper outer diameter：Max. 83 mm.
 Paper roller inner diameter： paper roll mandril inner diameter 12mm, paper roll
mandril outer diameter 18mm.
 Paper thickness：0.065 ～ 0.10mm.
2.2.2 Black mark paper specification
When using the black mark paper, the black mark paper must be at the front side of
the receipt paper, and the reflectivity should be less than 15%, and the reflectivity of
other part of the paper should be more than 85%. There must not be any graphics in
the black mark space, such as advertising. The black mark should be qualified for the
below requirement:
Fig 2.2.1
2.2.3 Notices
Notes：
 Pls. use the high quality thermal paper, otherwise it will influence
the printing quality and decrease the thermal printer head life；
 Don’t stick the paper on the paper roll mandril；
 If the thermal paper is polluted by chemical or oil, the thermal paper
heat sensibility decreases, which will influence the printing quality；
 Don’t use finger nail or hard articles to touch the surface o f thermal
paper, otherwise it will cause color fading ；
 When the environment temperature is higher than 70°C， the
thermal paper color will fade, so pay attention to the influence of
temperature, humidity and sunlight.
5mm<L1（black mark width）<10mm
L2（black mark length）>12mm
20mm<L3（the distance between two black mark）<500mm
