TP801/TP805/TP806 User Manual
www.hprt.com 11
2.3 Printing and cutting position
2.3.1 Printing position
Fig 2.3.1
1) L1 Paper house width：TP801/805－83mm,TP806－81±0.5mm
2)
L2 Valid printing width: 80mm
3) L3 The distance between the thermal printer head and the left side of the paper
house(fixed width)：3.5±0.3mm
4) L4 The distance between the thermal printer head and the right side of the paper
house(fixed width)：3.5±0.3mm
5) L5 The left side：default 4 mm
6) L6 Printing width： decided by the command (see the program guide), and the
default is 72mm.
7) L7 Te right side：default 4mm
2.3.2 Cutting position
Fig 2.3.2
