TP801/TP805/TP806 User Manual
www.hprt.com 18
Figure 4.6.1
3) Put the paper into printer（Like figure 4.6.2）
Figure 4.6.2
Notes：
► According to the paper size to adjust the paper holder;
► Make sure the end of the paper roll fit for the graphics requirements;
Figure 4.6.3
► Make sure the paper inside is at tight status, or it will tissue paper or other
obstacle.
4) Pull out of the end of paper roll, closed the cover and tear up sheet of paper.
