HPRT TP80BE User Manual

TP80BE User Manual
8
3 SPECIFICATION
3.1 Printer Specification
Item
Parameter
Printing
Parameter
Printing Method
Direct thermal line printing
Resolution
Default 203 dpi, 180 dpi can be emulated
Printing Width
72mm (576dots)
Printing Speed
Max. 230mm/s
Printing density
Adjustable from degree 1 to degree 4
Printing Direction
Vertical and horizontal
Interface
Default
Built-in USB, RS232,LAN
Optional
N/A
auto cutter
Partial Cut
Page mode
YES
Memory
RAM
16MB
Flash
4MB
Character set
Font
ANK Font A: 12*24 Font B: 9*17 CHN: GBK24*24
Number of Columns
48/64
Alphanumeric
95
Code page
PC437/Katakana/PC850/PC860/PC863/PC865/PC857/PC737/PC866/
PC852/PC858/KU42/TIS11/TIS18/PC720/WPC775/PC855/PC862/
PC864/ISO8859-2/ISO8859-7/WPC1250/WPC1251/WPC1253/
WPC1254/WPC1255/WPC1256/WPC1257/WPC1258/MIK/PC755/
Iran/IranII/Latvian/ISO8859-1/ISO8859-3/ISO8859-4/ISO8859-5/
ISO8859-6/ISO8859-8/ISO8859-9/PC856/PC3848/ISO8859-15/ISO88
59-7/WPC1252
Graphics
Support bitmap printing with different density and user defined
bitmap printing (Max. 40K for per bitmap, and Max. 256K for total)
Barcode
1D
UPC-A, UPC-E, EAN8, EAN13, CODE39, ITF, CODEBAR, CODE128,
CODE93
2D
QR code, PDF417
Detection
Sensor
Paper out, Cover Open
Power supply
Input
AC100V-240V 50-60HZ
Output
DC 24V±5%, 2.5A
Paper
Paper Loading
Up loading, Easy loading
Paper Type
Standard thermal paper
Paper Width
79.5±0.5mm
Paper Thickness
0.056~0.13mm
Paper Roll Diameter
83mm Max.
Condition
Operating
0~45℃/10~85%RH
Storage
-20~60℃/10~90%RH
