13
cover ,round the flywheel of magneto anti-clockwise to aim “T”at the
signal of fore cover on the left.
Note: The piston must be fixed to the dead enter. (Figure 2-2)
Figure 2-2
Remove cylinder valve cover,check the lash between the valve stem
by feeler gauge .
Valve clearance:inlet and exhaust valve: 0.05～0.08mm.
See figure 2-3.
Figure 2-3
Loose the lock nut,rotate the adjusting screw until it appears that
the feeler gauge be pulled .Then fasten the adjusting screw by valve
adjuster,tighten the lock nut and check the valve lash .Afterword install
the cylinder valve cover , vision hole cover,the fuel tank and cushion.
