99
rignt
Nut on bottomr rocker arm of the
rignt
40～50
Suspension nut
35～45
Nut connecting chain stay and
rocker support
40～50
Nut on fore wheel
45～55
Nut on rear wheel
45～50
6.3 Electrical circuits
the characteristic of the electrical circuits,
1.Actualize the electrial starting when it is at N,parking and brake.
2.When it is in the H gear,the H gear switch of the engine is on the
ground,the H gear is lighting by the CDI inner transistor to control the
dash light earth connection.
3.The function of the diode in this circuitry is that after parking and brake
to actualize the electrial starting .
4.The relay electrical source,to provide the electricity through the CDI
working,it can protect the relay and to extend the useful time.
5.Use the pan- fuse box,each operating circuit is working
independence,and easy to service,there is no connect with the inner cable
and the functional line,it is hard to emerge the dummy section.
