37
spring
spring block
oil needle
remove pilot screw
spring
washer
Note:the pilot screw is set at maximum performance.Before
removing pilot screwd,note the revolutions of screw in order to
fix it back.
remove float chamber cover
washer
remove float pin
float
triangular needle
remove the cover
nut
0-rings
spring
starting plunger
pilot jet
check the carburetor body
