67
2、Check if the tire has reached its maximum wear condition in which
case it should be replaced.
3、Check the joining condition of the tire and wheel hub. If the joint of
tire and wheel hub is loose, replace the tire immediately.
4、Check the vibration of tire/wheel hub. (Figure 4-2-13)
Vibration of assembled Tire must be controlled
within 3mm. Otherwise, please replace with new
tire.
Remove the tire for vibration test of the wheel hub.
Should the vibration exceed 1.2mm, the wheel
hub must be replaced.
5、Inspect the four conical bores on the wheel hub.
In occasion of angular distortion or wear, the wheel hub must
be replaced.
4.3.2.3 Assembly of wheel:
Attach wheel hub onto the wheel with M10 Conical ball Nuts
(4pcs)and dust-proof cover.(1pcs).
Fastening Torque: 45～55N.m
Caution: assemble the wheel in correct direction (shown
as the arrow). Front and Rear Wheels are not
interchangeable.
(Figure 4-2-17).
