lp-608 Rev. 000 Rel. 001 Date 3.15.18
6
Figure 2 - Dimensional Drawing
Specications and Dimensions Water Temperature Ratings
Models
Storage
Capacity
A B C D E F
Safety
Listing
Hot /
Cold
Inlets
Shipping
Weight
(Lbs. Est.)
Min.
Delivered
Temp.
Max.
Delivered
Temp.
High
Temp.
Limit
EVG080C2X045H 80 6 1/2” 69” 23 1/4” 60”
8”
27”
UL 174
3/4”
NPT
155
110
o
F
(43.3 C)
170
o
F
(76.6 C)
190
o
F
(87.8 C)
EVG100C2X045H 100
7 1/4”
61”
27”
52”
30 3/4”
210
EVG115C2X045H 115 69” 60” 228
Table 2 - Specications and Dimensions - *** Refers to Electrical Specications - See Table 3 for Electrical Specications
Models # Elements Available Wattage Voltage
Full Load Current in Amps
(Single Phase)
C2X045H 2 4,500 240 19
C2X055H 2 5,500 240 23
Table 3 - Electrical Specications Including Corresponding Wattages / Voltages / Amperages - **** Refers to Model Type and Gallon Size - See Table 2
for Model Specications and Dimensions
