16
LP-454 REV. 1.6.15
COLD WEATHER HANDLING – If the heater has been stored in a very cold location (BELOW 0
o
F) before installation, handle with care
until the plastic components come to room temperature.
Remove all sides of the shipping crate to allow the heater to be moved into its installation location.
PERFORMANCE SPECIFICATIONS FOR PHOENIX PLUS MODELS
TEMPERATURE RISE IN DEGREES FAHRENHEIT
Table 2 – Phoenix Plus Performance – 95% Thermal Efficiency Used for Calculations
PERFORMANCE EQUATIONS
Rated Input x .95
GPM = Temp Rise (
o
F) x 500 GPH = GPM x 60
PART 4 – HEATER PIPING
Failure to follow the instructions in this section WILL VOID the warranty and may result in property damage, serious injury, or death.
A. GENERAL PIPING INFORMATION
Use two wrenches when tightening water piping at heater. Use one wrench to prevent the heater return or supply line from turning.
Failure to prevent piping connections from turning could cause damage to heater components.
DO NOT pipe this water heater with black iron, galvanized steel, steel, or lead pipe. Doing so will result in premature product failure and
property damage, and WILL VOID the product warranty.
The heater control module uses temperature sensors to provide both high limit protection and modulating temperature control. The
control module also provides low water protection by sensing the water level in the tank. Some codes/jurisdictions may require
additional external controls.
Never use dielectric unions or galvanized steel fittings when connecting to a stainless steel storage tank or heater. Use only copper or
brass fittings. Teflon thread sealant must be used on all connections.
