AP7052DN&AP7152DN
Hardware Installation and Maintenance Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Signal cables include network cables, optical fibers, and user cables.
Power cables include the AC power cables and DC power cables.
Fill in labels according to specified requirements to keep consistency of labels in the equipment room.
Make a relevant statement in the self-check report.
5.4.1 Introduction to Labels
5.4.1.1 Label Materials
Features:
Thickness: 0.09 mm (0.004 in.)
Color: chalk white
Material: polyester (PET)
Ambient temperature: -29°C (-20.2°F) to +149°C (300.2°F)
Printed by a laser printer and written with a marker
Pass UL and CSA authentication
5.4.1.2 Type and Structure
Label for Signal Cables
The label for signal cables is L-shaped with fixed dimensions, as shown in Figure 5-154.
