Content
Meaning
Example
R: Receiving
interface
T: optical
transmitting
interface
-
Example of the Label
Figure 5-162 shows a sample label on an optical fiber.
Figure 5-162 Sample label on an optical fiber between two devices
A01
R
TO:
01 05 01
G01
T
01 01 01
The meaning of the label is listed in Figure 5-162.

"A01-01-05-01-R" indicates that the local end of the optical fiber is connected to the
optical receiving interface 01 in slot 5, chassis 01 in the cabinet in row A, column 01 in
the machine room.

"G01-01-01-01-T" indicates that the opposite end of the optical fiber is connected with
optical transmitting interface 01 in slot 01, chassis 01 in the cabinet in row G, column 01
in the machine room.
5.4.2.2 Labels for the Optical Fibers Connecting the Device and an ODF
Meaning of the Labels
Table 5-28 shows information on both sides of labels attached to an optical fiber between a
device and an optical distribution frame (ODF).
Table 5-28 Information on labels affixed to a fiber between a device and an ODF
Content
Meaning
Example
MN-B-C-D-R
/T
MN: cabinet
number
For example, A01.
B: chassis
number
Numbered in bottom-up order with two digits, for
example, 01.
C: physical slot
number
Numbered in top-down and left-right order starting
from 01. For example, 01 is the first slot at the top left
of the chassis.
D: optical
Numbered in top-down and left-right order, consistent
