Huawei AP7052DN User Manual

AP7052DN&AP7152DN
Hardware Installation and Maintenance Guide
2 AP Installation
Issue 01 (2017-12-29)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
2. Place an IoT card in the slot and tighten the card using M2.5x6 screws (with a tightening
torque of 0.3 Nm).
1. AP
2. IoT card
3. M2.5x6 screws
3. Connect an IoT antenna with the MMCX connector of an IoT card, and slide the IoT
card cover to secure the IoT card. When installing the IoT card cover, insert the
protrusion on the cover into the opening on the AP. Then press the protrusion until you
hear a click sound.

The diagonal size of a hexagon SMA connector must be less than or equal to 8 mm; otherwise, the
cable cannot be installed.

The ANT card has one radio port, and the RFID card has two.

Huawei AP7052DN Specifications

General

Brand	Huawei
Model	AP7052DN
Category	Wireless Access Point
Language	English
