Huawei eA660 Series - Ground Cable

eA660 Series CPE
User Guide
2 Hardware
Issue 06 (2019-04-03)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
18
2.2.2 Ground Cable
The ground cable ensures the proper grounding of the eA660.
Appearance
The ground cable provides a 6 mm² cross-section, is yellow-green, and has OT terminals at
both ends. Figure 2-4 shows the appearance of the ground cable.
Figure 2-4 Ground cable
Technical Specifications
Table 2-4 lists the technical specifications of the ground cable.
Table 2-4 Technical specifications of the ground cable
Name
Description
Color
Yellow-green
Cross-section
6 mm²
Outer diameter
5.1 mm
Working temperature range
–10°C to 70°C
