3.3.3 Mounting on the Wall (Without an Angle Adjusting
Component)
Prerequisites
The eA660 and mounting components are ready, as shown in Figure 3-22 and Table 3-4.
Figure 3-22 eA660 and wall-mounting components
Table 3-4 Wall-mounting components
No.
Name
1
Wall-mounting screw
2
Mounting frame
3
CPE
Context
Figure 3-23 shows the flowchart for mounting the CPE on the wall.
