eA660 Series CPE
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Connect one end of the PoE network cable to the adapter, as shown in Figure 3-48.
Figure 3-48 Connecting the PoE adapter
1. DATA port: connects to the compuer
network cable.
2. PoE port: connects to the PoE network
cable.
----End
3.4 Installation Check
After you install the eA660, perform a hardware installation check and a power-on check.
Prerequisites
The eA660 hardware has been installed.
Procedure
1 Check whether the eA660 hardware is correctly installed.
When performing the hardware check for the eA660, check the items listed in Table 3-6 in
order.
