3.3.2 Mounting on a Utility Pole (with an Angle Adjusting
Component)
Prerequisites
The eA660 and mounting components are ready, as shown in Figure 3-10 and Table 3-3.
Figure 3-10 eA660 and mounting components
Table 3-3 Mounting components
No.
Name
1
Angle adjusting component
2
Mounting frame
3
Hose clamp
4
CPE
Context
Figure 3-11 shows the flowchart for mounting the eA660 to a utility pole equipped with an
angle adjusting component.
