FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
3 System Architecture
Copyright © Huawei Technologies Co., Ltd.
35
Table 3-14 Battery cabinet technical specifications
Item
Specifications
Dimensions (H x W x D)
2000 mm x 600 mm x 1100 mm
Color
Black
Material
High-intensity class A carbon cold rolled steel plate and
zinc-coated steel plate
Air channel
Front and rear air channels
Installation space
42 U
Installation mode
Installed on a concrete floor or ESD floor
Door opening
The front door is a single door, and the rear door is a double
one.
Static load
1500 kg
Dynamic load
1000 kg
Weight
128 kg (excluding batteries)
Protection level
IP20
Table 3-15 lists the number of batteries with different capacity a single battery cabinet can
house.
Shoto battery is supported.
Table 3-15 Maximum number of batteries inside a single battery cabinet
Battery Specifications
Maximum Number of Batteries
Inside a Single Battery Cabinet
26 Ah
20
40 Ah
20
65 Ah
20
100 Ah
20
Table 3-16 Configuration scenarios (for both the main and auxiliary battery cabinets)
Battery Specifications
Layer (from Top to Bottom)
Number of
Batteries
26 Ah/40 Ah
Layer 1
10
Layer 2
10
