3.5 Port Application Diagram
The MS2131 contains the following ports, as shown in Figure 3-2.

USB2.0 port

SIM card slot (1.8 V or 3.0 V)

TS-5 external antenna port
Figure 3-2 MS2131 application diagram
MS2131
Application interfaces
USB SIM TS-5
SIM
card
External
antenna
RF
