6 MS2131 Structure Features and Design
Requirements
6.1 About This Chapter
This chapter describes the MS2131 structure features, including the system dimensions and
design requirements addressing the host structure. This chapter also describes the USB
connector dimensions and its design requirements and guides addressing the host structure.
6.2 Dimensions and Weight
The MS2131 has dimensions of 84.9 mm x 27 mm x 12.3 mm (including the USB cap) and
weighs about 30.0 g.
Figure 6-1 shows the outline dimensions of the MS2131.
Figure 6-1 MS2131 dimensions
