11.2 Appendix Two MS2131 OTA Data
Table 11-4 MS2131 TIS
Description
Bands Channel Test Value Units
WCDMA
Band I(W2100)
10562
-104
dBm
10700
10838
Band II
(W1900)
9662
-104
dBm
9800
9938
Band V(W850)
4357
-103
dBm
4408
4458
Band
VIII(W900)
2937
-102
dBm
3012
3088
GSM
GSM 850
128
-102
dBm
190
251
GSM 900
975
-102
dBm
37
124
GSM 1800
512
-103
dBm
698
885
GSM 1900
512
-103
dBm
661
810
Values in Table 11-4 are average values obtained from a certain number of test samples, which are tested
in the stacking conditions shown in Figure 5-2. The tests are implemented with a PC. If the stacking fails
to meet requirements made in section 5.4 "Antenna Design Requirements", the MS2131 performance
may worsen compared with data in Tab le 11-4.
