Table 11-5 MS2131 TRP
Description Bands Channel Test Value Units
WCDMA
Band I(W2100)
9612
19
dBm
9750
9888
Band II (W1900)
9662
14
dBm
9800
9938
Band V(W850)
4132
19.5
dBm
4183
4233
Band VIII(W900)
2712
19.5
dBm
2787
2863
GSM
GSM 850
128
27.5
dBm
190
251
GSM 900
975
29
dBm
37
124
GSM 1800
512
24
dBm
698
885
GSM 1900
512
23.5
dBm
661
810
The preceding values are average values obtained from a certain number of test samples. Figure 5-2
shows the MS2131 deployed in a PCB. Samples are tested deployed in the board. If the PCB is not
designed as required in section 5.4 "Antenna Design Requirements", the MS2131 performance may
worsen compared with data in Table 11-4.
