Huawei Quidway S5600 Series Installation Manual

Installation Manual
Quidway S5600 Series Ethernet Switches Chapter 1
Product Overview
Huawei Technologies Proprietary
1-8
LED Mark Status Description
Green
The port is operating at 1000
Mbps. The LED blinks quickly
when the port is receiving or
sending data.
Blinking
yellow (3
Hz)
The port fails the POST.
Speed mode
OFF The port is not connected.
Green
The port is operating in 1000
Mbps full duplex mode. The LED
blinks quickly when the port is
receiving or sending data.
Blinking
yellow (3
Hz)
The port fails the POST.
Duplex mode
OFF The port is not connected.
1000Base
SFP port
mode LED
PoE mode OFF
–
Table 1-3 LEDs on the S5624F
LED Mark Status Description
Solid green The switch is started normally.
Blinking green (at 1 Hz)
The system is running power-on
self-test (POST).
Solid red
The system fails the POST, or
there is another fault.
Blinking yellow (at 1 Hz)
Some ports fail the POST and
do not function.
Power
LED
PWR
OFF The switch is power-off.
Solid green
Both the AC power supply and
the DC input operate normally.
Solid yellow
The AC power supply fails or the
AC input is disconnected, while
the DC input operates normally.
DC LED RPS
OFF DC input is disconnected.
