2 Configuring the IPMI Settings
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
6
Values Meanings
-fru list Shows all FRU values
-fru help Shows FRU Write help
-fru cthelp Shows chassis type code
-fru <Field> Shows FRU field value
-fru<Field> < Value > Write FRU
-fru backup<Field> Backs up FRU to file
-fru restore<Field> Restore FRU from file
- fru Ver[<V1><V2>] Retrieves and sets FRU version(V1,V2)
----End
Accessing the Baseboard Management Controller
Step 1 Connect a LAN cable to the onboard LAN1 port or the dedicated IPMI LAN port.
Step 2 Choose a computer connected to the same network and open the IPMIView utility.
Step 3 Go to File>New>System. Enter System Name, IP Address of LAN1 or the dedicated LAN,
Description in the appropriate fields and press Enter.
Step 4 Select the system from the IPMI Domain. Enter the Login ID and Password in the appropriate
elds to login to the IPMIView utility.
----End
Using the Internet Browser
Step 1 Connect a LAN cable to the onboard LAN1 port or the dedicated IPMI LAN port.
Step 2 Choose a computer that is connected to the same network and open the browser.
Step 3 Enter the IP address of each server that you want to connect to in the address bar in your
browser.
Step 4 Once your machine is connected to the remote server, the Log-In screen as shown on the next
page will display.
User Guide
Issue 04 (2014-09-15)
RH2488 V2 BMC
