Huawei RH2488 V2 Server BMC User Manual

1 Introduction
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
2

Multiple ADC inputs, Analog and Digital Video outputs

Two serial ports (optional)

DDR2 SDRAM memory for frame-buffer, firmware support and data storage

SPI Flash Host BIOS and firmware bootstrap program supported

Reduced Media Independent Interface (RMII)

OS (Operating System) Independency

Provides remote Hardware Health Monitoring via IPMI. Key features include the
following:
−
Temperature monitoring
− Fan speed monitoring
−
Voltage monitoring
−
Power status monitoring, chassis intrusion monitoring
−
Remote power control to power-on, power-off or reboot a system
−
Remote access to text-based, graphic-based system information, including BIOS
configurations and OS operation information (KVM)
−
Remote management of utility/software applications

Provides Network Management Security via remote access/console redirection. Key
features include:
−
User authentication enhancement
−
Encryption support enhancement, allowing for password configuration security to
protect sensitive data transferring via Serial over LAN

Supports the following Management tools: IPMIView, CLI (Command Line Interface)

RMCP+ protocol supported
1.2 WPCM450 Block Diagram
Figure 1-1 represents a typical system setup for the WPCM450 Controller.
User Guide
Issue 04 (2014-09-15)
RH2488 V2 BMC
