Figure 3-3 shows RRU ports on the panels.
Figure 3-3 RRU ports on the panels
Table 3-1 describes RRU ports and indicators on the panels.
Table 3-1 RRU ports and indicators on the panels
Item
Label Description
(1) Ports at the bottom ANT0-ANT3 TX/RX port. ANT0 port supports RET signal
transmission.
RET/EXT_ALM Communication port for the RET antenna or
port for alarm reporting, supporting RET
signal transmission
RRU3232
Installation Guide 3 Information About the Installation
