Huawei SUN 2000 Series - Page 32

SUN2000-4.95KTL-JPL0
User Manual
4 Installation
Issue 03 (2020-06-03)
Copyright © Huawei Technologies Co., Ltd.
26
Figure 4-10 Determining hole positions
Step 2 Drill holes using a hammer drill.
You are advised to apply anti-rust paint on the hole positions for protection.
Figure 4-11 Drilling holes
Step 3 Secure the mounting bracket.
