Huawei SUN2000-5KTL-L1 User Manual

(M) FusionSolar App (N) 4G Smart Dongle (O) WLAN-FE Smart
Dongle
(P) Router (Q) FusionSolar Smart
PV Management System
NO TE
For detailed operations on devices in the network, see the following guides:
● SUN2000-450W-P Smart PV Optimizer Quick Guide
● LUNA2000-(5-30)-S0 User Manual
● Backup Box-(B0, B1) Quick Guide
CA UTION
The o-grid load output port of the Backup Box cannot be directly connected to
the power grid. Otherwise, the Backup Box will be shut down due to overload.
Supported Power Grid Types
The SUN2000 supports the following power grid types: TN-S, TN-C, TN-C-S, and
TT. In the TT power grid, the N-to-PE voltage must be less than 30 V.
SUN2000-(2KTL-6KTL)-L1
User Manual 2 Product Introduction
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 16

Huawei SUN2000-5KTL-L1 Specifications

General

Model	SUN2000-5KTL-L1
Max. Efficiency	98.4%
Rated AC Output Power	5000 W
Operating Temperature Range	-25°C to +60°C
Topology	Transformerless
Max. apparent AC power	5500 VA
Max. input voltage	600 V
Number of MPPT trackers	2
Max. short-circuit current per MPPT	15 A
Protection degree	IP65
Max. Input Power	7500 W
Output Frequency	50 Hz / 60 Hz
Cooling Method	Natural Convection
Nominal AC voltage	230 V
AC voltage range	180 V - 280 V
Rated Output Voltage	230 V
