Step 2 Drill holes using a hammer drill.
You are advised to apply anti-rust paint on the hole positions for protection.
Figure 4-13 Drilling holes
Step 3 Secure the mounting bracket.
Figure 4-14 Securing the mounting bracket
Prepare bolt assemblies based on the hole diameter of the mounting bracket.
SUN2000-(8K, 10K)-LC0 Series
User Manual 4 Installation
Issue 01 (2023-09-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 34
