Cable Pin Denit
ion
To
2 485A1 COM-1
RS485A1_INV
5 GND COM-4
DO_INV_CGND
8 DI2 COM-3 DO_INV
2 3 485B2 Battery 485B
4 485A2 485A
5 GND Enable-
6 EN+ Enable+
Step 2 Connect the signal cable connector to the COM port.
Figure 5-27 Securing the signal cable connector
----End
SUN2000-(8K, 10K)-LC0 Series
User Manual 5 Electrical Connections
Issue 01 (2023-09-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 65
