Figure 1-10 Lifting the SUN2000
2. Remove the two rubber screws from the top of the SUN2000 using a flat-head
screwdriver, and install two M10 lifting eyes, as shown in Figure 1-11.
Figure 1-11 Installing lifting eyes
3. Route a rope through the lifting eyes and hoist the SUN2000, as shown in Figure 1-12.
The rope must bear the SUN2000 weight.
When hoisting the SUN2000, keep balance to protect the SUN2000 from colliding with the
wall or other objects.
