SUN2000 (8KTL-28KTL)
Quick Installation Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
To prevent device damage and personal injury, keep balance when moving the SUN2000
because the SUN2000 is heavy.
Do not put the SUN2000 with its wiring terminals contacting the floor because the power
ports and signal ports are not designed to support the weight of the SUN2000. Place the
SUN2000 horizontally.
When placing the SUN2000 on the floor, put foam or paper under the SUN2000 to protect
its shell.
----End
4. Installing the SUN2000
If the installation location is near the ground, first connect the PGND cable to the ground before
installing the SUN2000 on the wall. For details, refer to 5 Connecting PGND Cables.
Step 1 Install the rear panel.
If you use a ladder to install the SUN2000 on a high position, keep balance to protect yourself
from falling down.
1. Determine the position for drilling holes, level hole positions, and then mark the hole
positions by using a marker, as shown in Figure 1-3.
