Huawei SUN2000-8KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
8 Maintenance
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
114
Alarm ID
Name
Severity
Causes
Measures
200
DC Bus
Voltage
Fault
Major
Abnormal external conditions
have triggered DC circuit
protection inside the
SUN2000. The possible causes
are as follows:

Reason ID = 3
The SUN2000 input is
suddenly disconnected, or
the shielded PV strings
result in a sharp change in
output power.

Reason ID = 9 or 11
The input energy of the
SUN2000 cannot be vented
quickly due to the sharp
change of grid voltage. As
a result, the internal
voltage increases.

Reason ID = 10
The internal control circuit
of the SUN2000 is unable
to keep up with changes
due to grid phase
imbalances.
a. The SUN2000 monitors its
external working conditions in
real time and automatically
reverts to normal operating status
after the fault is rectified.
b. If the alarm occurs repeatedly,
contact Huawei technical
support.

Huawei SUN2000-8KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
Nominal AC output power	8000 W
Weight	25 kg
Operating temperature range	-25°C to +60°C
Protection rating	IP65
Max. apparent AC power	8800 VA
AC grid frequency	50 Hz / 60 Hz
Starting voltage	200 V
Number of MPPTs	2
Cooling	Natural convection
Maximum DC Input Power	12000 W
Output Frequency	50 Hz / 60 Hz
Nominal AC voltage	230 V
Operating voltage range	200 V - 1000 V
Rated Output Voltage	230 V
MPPT Voltage Range	260 V - 850 V
