Huawei SUN2000-8KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
5 Electrical Connections
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
44
5.2 Connecting AC Output Power Cables
Connect the SUN2000 to the AC power distribution frame (PDF) or power grid using AC
output power cables. Ensure that the cable connections meet the requirements of the local
power grid operator.
Prerequisites
A three-phase AC switch needs to be configured outside the AC side of the SUN2000. To
ensure that the SUN2000 can safely disconnect from the power grid under abnormal
conditions, select an appropriate overcurrent protection device according to local power
distribution regulations.

Do not install a single circuit breaker for several SUN2000s.

Do not connect loads between the SUN2000 and circuit breaker.
Context
Flexible cables are recommended for ease of installation. The outer diameter of the cable
conductor should be less than or equal to 4.2 mm. Table 5-1 lists the specifications.
If the PID module is used in a PV array containing the SUN2000, verify that the working voltage of AC
cables to the ground is no less than 600 V AC, and that the voltage between AC cables is no less than
1000 V AC.

Huawei SUN2000-8KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
Nominal AC output power	8000 W
Weight	25 kg
Operating temperature range	-25°C to +60°C
Protection rating	IP65
Max. apparent AC power	8800 VA
AC grid frequency	50 Hz / 60 Hz
Starting voltage	200 V
Number of MPPTs	2
Cooling	Natural convection
Maximum DC Input Power	12000 W
Output Frequency	50 Hz / 60 Hz
Nominal AC voltage	230 V
Operating voltage range	200 V - 1000 V
Rated Output Voltage	230 V
MPPT Voltage Range	260 V - 850 V
