Huawei SUN2000-8KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
6 System Operation
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
67
After the initialization parameters are set for multiple SUN2000s in the same network, set the
address and baud rate for each SUN2000 based on the following rules:

Every SUN2000 in the same daisy chain must have a unique address. If communication
with the SmartLogger is required, every SUN2000 in the daisy chain must have a unique
address within the address scope configured for the SmartLogger.

All SUN2000s in the same daisy chain must have the same baud rate. If communication
with the SmartLogger is required, all SUN2000s in the daisy chain must have the same
baud rate configured for the SmartLogger.
----End

Huawei SUN2000-8KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
Nominal AC output power	8000 W
Weight	25 kg
Operating temperature range	-25°C to +60°C
Protection rating	IP65
Max. apparent AC power	8800 VA
AC grid frequency	50 Hz / 60 Hz
Starting voltage	200 V
Number of MPPTs	2
Cooling	Natural convection
Maximum DC Input Power	12000 W
Output Frequency	50 Hz / 60 Hz
Nominal AC voltage	230 V
Operating voltage range	200 V - 1000 V
Rated Output Voltage	230 V
MPPT Voltage Range	260 V - 850 V
