Huawei SUN2000-8KTL User Manual

SUN2000 (8KTL-28KTL)
User Manual
7 Man-Machine Interaction
Issue 10 (2017-07-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
82
LCD
Procedure
1. On the default screen, press to enter
the main menu.
2. Choose and press .
3. Enter the correct user name and password
by pressing or , and press .
NOTE

The optional user names are Common User and
Advanced User. The initial password for
Common User and Advanced User is 000001.
If you forgot the password, contact Huawei
technical support for a dynamic password that is
effective only on the current day. Change the
password after login.

After the authentication is successful, the
system keeps the authentication information for
30 seconds. If you exit from the Settings screen
and log in again within 30 seconds, no
authentication is required.
An Advanced User has logged in to the
SUN2000.
4. Choose User Param. and press .

Huawei SUN2000-8KTL Specifications

General

Max. efficiency	98.6%
European efficiency	98.3%
Max. DC voltage	1100 V
Nominal AC output power	8000 W
Weight	25 kg
Operating temperature range	-25°C to +60°C
Protection rating	IP65
Max. apparent AC power	8800 VA
AC grid frequency	50 Hz / 60 Hz
Starting voltage	200 V
Number of MPPTs	2
Cooling	Natural convection
Maximum DC Input Power	12000 W
Output Frequency	50 Hz / 60 Hz
Nominal AC voltage	230 V
Operating voltage range	200 V - 1000 V
Rated Output Voltage	230 V
MPPT Voltage Range	260 V - 850 V
