Huawei SUN2000 L1 Series User Manual

2
3
Space Angle
2
Installing the Device
Mounting Hole Dimensions
Installation Requirements
2.1
Avoid drilling holes in the water pipes and cables buried in the wall.
1. Install the mounting bracket.
Installing the Solar Inverter
2.2

Huawei SUN2000 L1 Series Specifications

General

Max. Efficiency	98.6%
Number of MPP Trackers	2
Output Frequency	50 Hz / 60 Hz
Protection Class	IP65
Cooling	Natural Convection
Type	String Inverter
Output Voltage	230 V
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
Total Harmonic Distortion (THD)	≤ 3%
DC Injection Current	<0.5% of rated output current
Operating Temperature Range	-25 °C ~ +60 °C
Relative Humidity (Operating)	0% - 100% (non-condensing)
Communication	RS485
