Huawei SUN2000 M5 Series User Manual

Table 2-1 Model description
No. Meaning Value
1 Series name SUN2000: three-phase grid-tied PV string
inverter
2 Power level ● 12K: The rated power is 12 kW.
● 15K: The rated power is 15 kW.
● 17K: The rated power is 17 kW.
● 20K: The rated power is 20 kW.
● 25K: The rated power is 25 kW.
3 Topology TL: transformerless
4 Sales region ZH: China
5 Product code M5: product series with an input voltage level
of 1100 V DC
Supported Power Grids
Power grid types supported by the SUN2000 include TN-S, TN-C, TN-C-S, TT, and
IT.
Figure 2-2 Supported power grids
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 2 Overview
Issue 03 (2023-02-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 14

Huawei SUN2000 M5 Series Specifications

General

Max Efficiency	98.6%
Max Input Voltage	1100 V
MPPT Operating Voltage Range	200 V - 1000 V
Operating Temperature Range	-25°C to +60°C
Communication	RS485, 4G (optional)
