DIP switch S2 is used to set the type of external analog sensors. Table 4-4 describes the meanings
and settings of S2 on the H304ESC.
Table 4-4 Setting of S2 on the H304ESC
DIP Switch Setting Meaning Default
Setting
S2-1 ON The external sensor of JTA1 is of the
current type
OFF
OFF The external sensor of JTA1 is of the
voltage type
S2-2 ON The external sensor of JTA2 is of the
current type
OFF
OFF The external sensor of JTA2 is of the
voltage type
S2-3 ON The external sensor of JTA3 is of the
current type
OFF
OFF The external sensor of JTA3 is of the
voltage type
S2-4 Reserved Unavailable -
DIP switch S3 is used to set the reporting mode and rate. Table 4-5 describes the settings of S3
on the H304ESC.
Table 4-5 Settings of S3 on the H304ESC
DIP Switch
Setting Meaning Default
Setting
S3-1 ON The H304ESC is used in the access network ON
OFF The H304ESC is used in the exchange
S3-2 ON The H304ESC uses one serial port for
reporting
OFF
OFF The H304ESC uses two serial ports for
reporting
S3-3 Reserved Unavailable -
S3-4 ON The reporting rate of the serial port is 19200
bit/s
OFF
OFF The reporting rate of the serial port is 9600 bit/
s
S3-5 to S3-8 Reserved Unavailable -
