Table 7-7 Settings of the Dip switchs 1-5
5 4 3 2 1 Address Value
0 0 0 0 0 0
0 0 0 0 1 1
0 0 0 1 0 2
0 0 0 1 1 3
0 0 1 0 0 4
0 0 1 0 1 5
0 0 1 1 0 6
0 0 1 1 1 7
0 1 0 0 0 8
0 1 0 0 1 9
0 1 0 1 0 A
0 1 0 1 1 B
0 1 1 0 0 C
0 1 1 0 1 D
0 1 1 1 0 E
0 1 1 1 1 F
1 0 0 0 0 10
.. .. .. .. .. ..
The DIP switchs 6-7 are used to set the rate of the serial port, Table 7-8 shows the settings of
the Dip switchs.
Table 7-8 Settings of the Dip switchs 6-7
7
6 Rate Value
0 0 4800bit/s
0 1 9600bit/s
1 1 19200bit/s
Specifications
Table 7-9 lists the specifications of the EPS75-4815AF power system.
