To create a new program, continue as follows:
1. Select the menu point Enter program from the Compact / Comfort menu.
2. Select the program number to be used. Information on the number of segments
from the program currently used etc is shown in the lower part of the graphic
display screen (60).
3. After having selected the program to be edited you are being offered several
functions. Normally you would start with the sub menu
a. Segments.
Confirm by pressing the key / rotary knob (61). The cursor (frame) first indicates
the set-point (SP). By turning the key / rotary knob (61) the individual functions
such as (segment time, temperature control mode…) can be chosen. The
activated function (frame) can be modified and saved by turning to the desired
value and pressing the key / rotary knob (61). Please note, that when selecting
an exponential ramp function (E-Grade Professional) the end value (more
precisely 99% of the end value) will be reached after 5 times the time constant
has elapsed. After having made all inputs select “SAVE” and confirm by pressing
the key / rotary knob (61) to save the segment.
By means of the function (soft-key) “DEL”, “INS” and “BACK” segments may be
inserted easily and deleted. Choose the segment to be deleted by turning the key
/ rotary knob (61) or to insert a new segment.
or
b. Segments (List).
The main functions set-point (SP), time, mode and stability are listed for entry
and modification. Lines are being chosen by turning the key / rotary knob (61)
and columns by simultaneously turning and pressing of the key / rotary knob
(61).
The activated function (frame) can be modified and saved by pressing further
turning to the desired value and pressing again the key / rotary knob (61).
By means of the function (soft-key) “DEL”, “INS” and “BACK” segments may be
easily inserted and deleted. Choose the segment to be deleted by turning the key
/ rotary knob (61) or to insert a new segment.
4. Via the sub menu point End condition, available options for the end of the
program (e.g. Stop temperature control, or Continue temperature control) can be
chosen.
5. A new program name can be entered from the menu point Input program name
by means of the keys from the touch screen (60).
6. To delete a program, use the Delete program option from the sub menu.
7. After entering a program, the Program start & stop option from the main menu
can be used to call up, run and stop it. An early stop to the program can also be
achieved by selecting the main menu point Program start & stop.
