Exchange of the CC Electronics / Remote Control
Disconnect the thermostat from mains power by turning the main switch (36) to OFF.
Pull out the power plug. In the case of a problem with the electronics, you can
exchange these parts yourself or prepare it for use as a remote control. For questions or
difficulties please contact our representatives or ourselves.
- Remove the lock (anti-clockwise) for securing the CC-Pilot on the front side of
the CC-Pilot, and pull the Pilot carefully up and away.
- Place the replacement CC-Pilot carefully in place and fasten it with the locking
(clockwise)
Remote Control:
An unrigged CC-Pilot Controller can also be used as a remote control. Therefore, mount
the connection wire (order no. #16160) between the machine and the CC-Pilot.
-2048
Internal actual value has
exceeded alarm tem
p
erature
Check alarm limits
-2049
-2050
-2051
-2052
-2053
-2064
-2068
-2072
-2075
-2095
Internal actual value has fallen
below alarm tem
p
erature
Process actual value has
exceeded alarm tem
p
erature
Process actual value has fallen
below alarm tem
p
erature
Analogue input is selected.
Si
g
nal is fault
y
. Under/over scale
Analogue input is selected.
Si
g
nal is fault
y
. Near limit
Pump pressure is too high
Temperature difference control
sensor, and OT sensor too hi
g
h
Over-temperature in expansion
tank almost reached
Actual value lies outside
set-
p
oint ran
g
e
Caution: Level too low. Switch
off will take
p
lace shortl
y
.
Check alarm limits
Check alarm limits
Check alarm limits
Please note chapter on: analogue interface
Please note chapter on: analogue interface
Flow resistor is too high. Improve thermo regulation by
e.
g
. better cross-section enlar
g
ement of the hoses
Improve thermo regulation by e.g. higher pump speed,
enlar
g
e the cross-section of the hoses
Please note chapter on „setting the over-temperature”
Check set-point limits
Possibly insufficient thermal fluid in the circuit. Fill in
thermal fluid.
