Function Numbers and their meaning
A detailed description of the functions, as well as an alternate operation for the menu
guide can be found in the chapter Compact-/ Comfort-/ Com.G@te menu
F0 Set-point
minimum set-point <= set-point <= maximum set-point
If an attempt is made to enter a set-point outside these limits, then a warning message
will be shown on the display (60) and the set-point will not be accepted.
F1 Minimum set-point, F2 Maximum set-point
The range for the set-point limits should conform to the safety data sheet of the
thermal fluid being used and the working temperature range allowed by the
administrator.
F3 Temperature control mode
Internal temperature control or process temperature control.
F4 2
nd
set-point
Alternate set-point which is being entered after activation.
Please also note the setting of function F28 (External control signal).
F5 Auto-Start
Auto-Start function= ON / Temp. control active.
After power loss – Temperature control will be restarted on return of power.
Auto-Start function = OFF / Standby
Temperature control will not be restarted when power restored (Default setting)
Caution!
The end-user should assess the risk and consequences of this setting for their
application. Default setting is OFF.
F6 POCO maximum limit (Pot. free Contact Maximum temperature)
Used in conjunction with function F8. This function sets the upper limit (Delta T)
relative to the set-point.
F7 POCO minimum limit (Pot. free Contact Minimum temperature)
Used in conjunction with function F8. This function sets the lower limit (Delta T)
relative to the set-point.
