Hubner FG 40 Series User Manual

Incremental Encoder FG 40
FG40_MANUAL-en_R12(2018-10-31)ID74490.doc
11
Protection class
acc. to
DIN EN 60529
Sealing
Permissible
speed
Rotor moment of
inertia
Breakaway torque
IP65
Standard
≤ 6000 min
-1
510 gcm²
6 Ncm
IP66
with labyrinth seal
≤ 6000 min
-1
580 gcm²
6 Ncm
IP66/IP67
with axial shaft
seal
≤ 4000 min
-1
510 gcm²
8 Ncm
IP66/IP67
with radial shaft
seal (for special
applications, e.g.
wet areas in
rolling mills)
≤ 3000 min
-1
510 gcm²
9 Ncm
Encoder temperature ranges
Standard
0°C… + 70°C
Special temperature ranges
-25°C… + 85°C
-40°C… + 85°C
-5°C… + 100°C
Special output voltage 5V (TTL)
Pulse height
5V, RS422-compatible (TIA/EIA-Standard)
Supply voltage
12… 30 V DC (optional: 5V DC)
Vibration resistance
DIN EN 60068-2-6 / IEC 68-2-6 (10 … 2000 Hz)
20 g (=200 m/s²)
Shock resistance
DIN EN 60068-2-27 / IEC 68-2-27 (6 ms)
150 g (=1500 m/s²)
Max. encoder shaft load
Fa, max. (axial) = 100 N
Fr, max. (radial) = 120 N
Shaft dimensions
11j6 x 30 mm (standard)
14j6 x 30 mm (optional)
Weight
Type AK
Type K
Type KK
approx. 2,8 kg
approx. 3,1 kg
approx. 3,6 kg
